T21 UN3394 Portable Tank Cylinder 1880L for TEAL Trimethylaluminum (TMA) Trimethylgallium (TMG)
T21 tank C480S
Portable Tank Container
tank capacity 1880L/1.88m3
FOR UN3394 ,UN3399
with fusible plug in addition to the Relief valve
ADR/RID BV ASME CERTIFICATE
All Gaskets firms Klingersil(High Temperature Resistance Gasket),
Liquid Vavle 1 1/4 inch DN32 Class 150，Gas Vavle 3/4inch DN20 Class 600,
High Quality Strong Safty Valve Xingguang Brand
Max. gross mass : 4000 kg
Tare : 1050 kg Payload : 2950 kg
| TMGa | TEGa | TMIn | TMAI | |
| Formula | Ga(CH3)3 | Ga(C2H5)3 | In(CH3)3 | AI(CH3)3 |
| Purity | 6N | 6N | 6N | 4N, 5N, 6N |
| Grade | Electronic Material | Electronic Material | Electronic Material | Electronic Material |
| Package | T21 UN Portable tank | T21 UN Portable tank | T21 UN Portable tank | T21 UN Portable tank |
| BVCT : BVCT2470336/S | Report N° : CN-2024-RZH-00013 | ||||
| Manufacturer: Keystone Vessel Manufacturing Co., Ltd. Country : CHINA | |||||
| Max. gross mass: 4000 kg | Tare: 1050 kg | Payload : 2950 kg | |||
| Owner: AP | Operator: | ||||
| Portable Tank Instruction : T21 | ADR/RID Tank Code: | Speciai Provisions: TP2 TP7 TP36 TP41 | |||
Model : KS1880-T21 ISO size/Type code : NA Type: UN Portable Tank Prototype Ref: BVCT2370646/S Dimensions : 2128x1148x1388 mm | |||||
| SUBSTANCES SUITABLE FOR TRANSPORT : | UN3394+UN3399 | ||||
| Nominal capacity : 1880 L Measured capacity : 1880 L at 20°C Max. allowable working pressure : 14.00 bar Test pressure : 21.00 bar | APPROVALS** IMDG : F/BV/23/194-T21 ADR/RID : F/9151/BV/24 TIR* : GB/C 26839 BV/2023 US-DOT CFR49 : UN Portable Tank | ||||
5 Units Keystone Vessel T21 TEAL UN Portable Tank C480 Cylinder To SAUDI ARABIA
