5 Units Keystone Vessel T21 TEAL UN Portable Tank C480 Cylinder To SAUDI ARABIA

Model : KS1880-T21

ISO size/Type code : NA Type: UN Portable Tank Prototype Ref: BVCT2370646/S Dimensions : 2128x1148x1388 mm

KSVU2400114

KSVU2400120

KSVU2400135

KSVU2400140

KSVU2400156

PORTABLE TANK

(EMPTY AND NEW TANKS)

HS.CODE:8609009000

5UNITS

5350

KG

5350

KG

2128x1148x1445 mm

5unitS

Total 17.65CBM

GENERAL DRAWING N°

DESIGN

Design code

Design temperature Design pressure

External design pressure

MATERIALS

KS1880-00 Rev.2

ASME VIII-1 2023ED min             -40 °C

14.00           bar 1.03             bar

max

9.87 mm

9.87 mm

65 °C

Setting

Frame

Tank Shell    Tank Heads

TANK

External diameter

SA-516M Gr.485 + GB/T 713 Q345R SA-516M Gr.485

SA-516M Gr.485

1148.00      mm

Shell

Heads

Nominal Nominal

12.00 mm

12.00 mm

Minimum Minimum

Equivalent thickness in reference steel

Shell    Heads

External tank area

EQUIPMENT

Heater type

Heater work pressure Heater test pressure

Surface area

Outlet       Top

Bottom

SAFETY DEVICES

Relief valves Nb

Relief valve 1 type

Relief valve 2 type

Flame resistant gauze Rupture disc 1 type      Rupture disc 2 type      Mounting

Installed vent capacity  Minimum vent capacity

COATING / INSULATION

Internal

12.15

12.15

8.60

None N/A

N/A

Yes No

1

SF/A412F-25P-(3B)

NO

N/A

1.35 Nm³/S   0.788 Nm³/S

/

mm

mm

m²

m²

Closures

Serial N°

External

+ 15.40 bar

PROTOTYPE TESTS

R

Stacking at

Transverse Racking test force

Impact test at SRS obtained at R =

4000 KG

MARKING Drawing. N°                                     KS1880-20 Rev.0 & KS1880-24 (AP) Rev.0

This tank has been manufactured under BUREAU VERITAS survey, in accordance with the following prescriptions :

Rules of   BUREAU VERITAS - ETTC GM

Code        IMDG

ADR/RID

The inspections performed are subject to reports BVCT2470336/S

INSPECTIONS PERFORMED

Verification of the conformity with the prototype.     Visual internal and external inspection of the tank. Visual inspection of the frame.

Hydrostatic pressure test of the tank:

- At a pressure of  21.00  bar

- Performed on :   13-08-2024

Leakproofness test of the tank equipment:

- At a pressure of    12.6   bar

- Performed on :    16-08-2024

Satisfactory operation of the service equipment. Verification of the markings.

Review of radiographic test reports:

- Circumferential and longitudinal shell welds:     100%

- Welds in head section:   100%

REMARKS

- Date of next statutory examination:   02-2027

- Date of next CSC examination:   08-2029

ASME Certification Mark with U; Fusible element setting 177°C

* Manufacturers responsibility to obtain the approval

** ADR/RID/IMDG/CSC are covered by the accreditation n°3-1352
