Keystone Vessel Manufacturing Authorized by ASME U R Keystone Vessel Manufacturing Co.,Ltd (KSVESSEL) is a leading developer and provider of high-quality storage and transportation packaging solutions for global hazardous media. Pressure Vessel ,ISOTank,UN Portable Tanks ,High Purity Ultrapure Industrial Gas Cylinders

Full Frame T11 UN Portable Tank SPECIFICATION FF3A-26-T11-L4BN-SPIC-P21067 1.1 Design Code Design Standards ASME VIII DIV. 1/EN 14025 1.2 Maximum Gross Mass 36000 kg 1.3 Nominal Capacity 26000 liters (0, -1.5%) 1.4 Vessel Design Temperature Tank body design temperature -40 ° C to+150 ° C 1.5 Maximum Product Loading Temperature (atm.) 150 ° C 1.6 Maximum Allowable Working Pressure 4.0 bar Hydrostatic Test Pressure 6.0 bar Maximum External Pressure 0.41 bar 1.7 Tare Mass Tank Box Self Weight 3560 kg (± 3%) 1.8 Frame (length/width/height) Dimensions (length/width/height) 6058/2438/2591mm

Full Frame T11 UN Portable Tank L4BN 25KL Stainless Steel SPECIFICATION FF3A-25-T11-L4BN-P23043 General Parameters 1.1 Design Code ASME VIII DIV. 1 / EN14025 1.2 Maximum Gross Mass 36000 kg 1.3 Nominal Capacity 25000 litre (± 1.0%) 1.4 Vessel Design Temperature -40 to +130 °C 1.5 Maximum Product Loading Temperature (atm.) 130 °C 1.6 Maximum Allowable Working Pressure 4.0 bar Hydrostatic Test Pressure 6.0 bar Maximum External Pressure 0.41 bar 1.7 Tare Mass 3480 kg (±3%) 1.8 Frame (length / width / height) 6058 / 2438 / 2591mm

High Pressure Surge Vessel Tank Cooler Delivery to Uzbekistan
