Stainless L4BN ISO T11 UN Portable Tanks 26KL

More >>
NEW STOCK
PRODUCT DETAIL
You are here: Home » Industrial Gas Cylinders » High Purity Gas Cylinder » Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

5 0 Reviews
Share to:
sharethis sharing button
Availability:
Quantity:

Acid Fuel Gas Tank Container Double Skinned IMO 1 IMO 5 Tank (20,000 - 24,000 Liter)

ISO Tank Container For Hazardous Liquids

Road transport Tank Container

T4,T6,T7,T8,T9, T10,T11,T14,T50 Portable Tank Offshore Tank Containers;

Steel Lined LDPE aslo for HCL(max 35%), NaOH (max 50%), NaCLO (max 10%), PAC (max 17%),H2SO4(60%,98%) ,HF ( 48%),H3PO4 (10%-85%),NH3. H2O,H2O2 (30%)
Compounds, cleaning liquid, UN1760,
Corrosive liquid, acidic, inorganic, n.o.s., UN3264,
Corrosive liquid, acidic, organic, n.o.s., UN3265,
Corrosive liquid, basic, inorganic, n.o.s., UN3266,
Hypochlorite solutions, UN1791,
Hydrochloric acid solution, UN1789,
Sulfuric acid, UN2796,
BATTERY FLUID, ALKALI UN 2797,
Hydrochloric Acid HCl UN1789
HCl (max 35%), NaOH (max 50%), NaCLO (max 10%), PAC (max 17%),H2SO4(60%,98%) ,HF ( 48%),H3PO4 (10%-85%),NH3. H2O,H2O2 (30%)etc

ISOTANK List

The Main Technical Parameters of Tanks (ASME Standard)


Item

Loading Medium

Model

Capacity
(m3)

Design
Pressure
(Mpa)

Design
Temperature
(c)

Tank Material

Nominal Tank
Thickness (mm)

Insulation

Tare weight
(Kg)

Max. Gross Weight
(Kg)

Dimension
(LX WX H)(mm)

Loading Method

1

R134a

T50

24

1.38

-40 /+55

SA-612N

11

Sunshade

6400

34000

6058 X 2438 X2591

Down load unload

2

R22

22

2.1

-40/+50

18

8800

3

R143a

22

2.42

20

9500

4

R125

22

2.75

21

9500

5

R32

20

3.44

25

10900

6

AHF

T19

21

1.0

-40/+55

SA516M NGr.485

12

No

6900

Up load unload

7

Trichlorosilan

T14

21

0.5

-40/+50

Q345R
(16MnR)

12

No

6780

34000

6058 X 2438 X2591

8

Liquid Chlorine

T50

20

1.7

-40/+50

16

8300

9

21.72

1.62

16

8900

10

Liquid
Ammonia

T50

21.6

2.2

-40/+50

06Cr19Ni10

22

Packing Insulation

11970

11

SO2

T20

21

1.03

40 /+60

16MnDR

12

No

6900

12

Cryogenic Liquid

T75

19.8,20

0.75-2.35

-196/+50

Inner Tank: 06Cr19Ni10
Outside Tank:Q345R

Vacuum With Mutli-wrapped

8600/12880

Down load unload

The Main Technical Parameters of Tanks (China Standard)


Item

Loading Medium

Model

Capacity
(m3)

Design
Pressure
(Mpa)

Design
Temperature
(c)

Tank Material

Nominal Tank
Thickness (mm)

Insulation

Tare weight
(Kg)

Max. Gross Weight
(Kg)

Dimension
(LX WX H)(mm)

Loading Method

1

R134a

T50

24

1.38

-40 /55

Q345 (16MnR)

12

Sunshade

6500

34000

6058 X 2438 X2591

Down load unload

2

R22

20

2.1

-40/+50

16

7850

3

24

18

9100

4

R125

22

2.75

22

9900

5

R32

22

3.44

28

12000

6

23.7

-40 /55

12700

Our Advantages

Custermizing Portable iso Tank Container tank container

Tank container main Technical Parameters
20FT tankcontainer 30FT tank container 40FT tank container
Overall dimension(mm) 6058×2438×2438/2591 9144×2438×2438/2591 12192×2438×2438/2591
Working temperature(ºC) -42C-60C
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)




ISO lined Tank,lined tank, Lined LLDPE tank, hcl Tank, acid tank, tank container, 20ft tank container , iso tank,isotank, iso tank container, t14 tank, offshore tanks, IMO 1 tank,imdg tank,acid tank container,Hydrochloric Acid tank,hydrochloric acid fluid tank, T14 Sulfuric Acid Tank Container,Steel Lined LDPE Tanker,Hypochlorite Ferric tank, FECL3 tank,Offshore Acid Tank,20ft tank ,20ft container tank, Horizontal Tank in Rectangular Frame,acid tank in Rectangular Frame,lined with Linear Low Density Polyethylene tank,offshore tanks suitable for transporting acid,Ferric Chloride tank,Sodium hydrogen sulphite solution tank,tanks containers for Hydrofluoric acid ,

ISO Tank

ISO 40' LNG Tank Container

Bitumen tank container

ISO 20' Tank Container

IMO 1
Shell made from 316 Stainless Steel
Capacity of 12,000 - 26,500 litres nominal
MAWP of 4 bar
For transport of: Hazardous liquids
Available in 7.65, 10, 20, or 30 foot sizes
Swap-bodies 7.65m and 7.82 (30,000-35,000 litres)
Heating by steam or electric heating (optional)

IMO 0
Shell made from 316 Stainless Steel
Capacity of 12000 - 26500 litres nominal
MAWP of 4 bar
For transport of
Wine
Fruit Juices
Vegetable Oils
Mineral Oils
Non-hazardous Oils
Available in 20 foot / 6 metres
Swap-bodies 7.65m and 7.82 (30,000-35,000 litres)
Heating by steam or electric heating (optional)


IMO 2
Shell made from 316 Stainless Steel
Capacity of 12,000 - 26,500 litres nominal
MAWP of 1.75 bar
For transport of:Low Hazardous liquids
Available in 7.65, 10, 20, or 30 foot sizes
Swap-bodies 7.65m and 7.82 (30,000-35,000 L)
Heating by steam or electric heating

Bitumen Tank Containers
Shell made from Carbon Steel
Capacity of 20,000-25,000 litres nominal
MAWP of 1.75 bar
Low Hazardous liquids
Available in 20 or 30 foot sizes
Heating by direct flame, hot oil or electric heating

Cement Containers
Capacity of 17.5 - 25 cubic metres
Pressure discharge
Road transport tank container
T4,T6,T7,T8,T9, T10,T11,T14,T50 portable tank;

PE Lined steel tanks for hydrofluoric acid liquid ,hydrochloric acid ,sodium hypochlorite HCl,NaOH,NaClO liquid etc.

IMO 5
Shell made from 316 Stainless Steel
Capacity of 15,000 - 25,500 litres nominal
MAWP of 1.75 bar
For transport of gases, including:
Propane
Butane
Refrigerants
Available in 20, 30 or 40 foot sizes
IMO 7
Shell made from 316 Stainless Steel or Carbon Steel
Capacity of 20,000 - 24,000 litres nominal
MAWP of 8 bar
For transport of cryogenic gases, including:
LNG
Available in 10, 20, 30 or 40 foot sizes
Offshore
Shell made from 316 Stainless Steel
Capacity of 2,000 - 10,000 litres
MAWP of 5 bar
For transport of gases, including:
Hazardous chemicals
Acid
Petroleum
Available in 8 x 8 x 10 sizes

https://youtu.be/77W3oSM7KAU
https://youtu.be/pAEXHFBdGdY
https://youtu.be/3Y0tT7nknXM
https://youtu.be/3Yb2diEGXyY
https://youtu.be/VKVIcC02974
https://youtu.be/uqva7K_GLB4
https://youtu.be/YViOkhVwMKg
https://youtu.be/II0khjBNAPs

Detailed Photos

20 Feet Q235B+PE Linging Acid Sodium Salt Liquid ISO Tank Container for Corrosive Sodium 3-Chloro-2-Hydroxypropanesulfonate 20kl Drilling Fluid Petrochemicals

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

T14 Un Portable Tanks for Offshore Ship Transport 55% Hydrofluoric Acid Un1790, 38% Hydrochloric Acid Un1789 (21KL 20FT 22K2 ISO TANK CONTAINER)

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

20FT T50 Liquid Chlorine Isotank Container Cl2 Un1017 Max Storage Pressure 1.5MPa 21670L

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

Product Parameters

Fuel Tank Container Double Skinned IMO 1 Tank (20,000 - 24,000 Liter)
IMO 5, T50 refrigerants, Ammonia, Chlorine, LPG and gas tanks
IMO 1, 20 ft ISO carbon steel bunded tank container with a capacity range between 20.000 and 24.000 liters.
Designed to be suited for both transport as well as on-site storage, with a service area for installing ancillary equipment such as fuel dispensing units and metering systems

The pictures are for your reference only.

ISO Tank Container 20 FT For Hazardous Liquids

Road transport Tank Container

T4,T6,T7,T8,T9, T10,T11,T14,T50 portable tank;

Size : 20 feet
Length : +6.058- 6.06 m
Width : +2.438- 2.44 m
Height : 2.438/2.591- 2.60 m

20FT 20000Liters Stainless Steel Nitric Acid HNO3, HF Acid, NAOH Sodium Hydroxide ISO Tank Container SS30408

UN T7 ,T14 Portable Tank, PE Lining Tank

Product name

20FT tank container
PE Lined
model DRZ
Transport medium Sulfuric Acid Volume 18.5 - 20 CBM
Dimensions (mm) 6058*2438*2591 Tank size (mm) Outside: 5850*2200*2100
Weight (kg) 5170 design standards National standard
Production cycle 30 workingdays Warranty/Certificate Have

Product parameters (main configuration)

Item Specification
Tank material Cartridge Q235 carbon steel /5mm/6mm
Beam material Q235B
shape Rectangular
Curb weight (kg) 5170
Head thickness 5mm
Tank thickness 5mm
The thickness of the lining 16mm
Lining material PE / LDPE /LLDPE
15mm,16mm,18mm,20mm
breather valve 2
Manual butterfly valves 1
Manhole 2 piece
Discharge valve 2 piece
colour According to user requirements
Wave breaker 2 pieces

Product Description

UN1830 Sulfuric acid with 92~94% acid ISO Tank ,UN T14 Portable Tank, PE Lining Tank

Characteristics Specification
Model UN T14 Portable Tank
Appointment UN1830 Sulfuric acid with 92~94% acid
volume 17.5/18.5
External dimensions 6058*2438*2438
Maximum loading capacity 36000
Operating pressure Normal
Design pressure 0.4
Pressure at test 0.6
Design temperature -40~ +50 ºC
Tank material Carbon steel SA-516M
Shell materat thickness 6
Head material thickness 8
Internal protective insert LLDPE7042 16mm
Frame material Q345D
Baffle None
Heat-insulating material 50mm thick mineral wool covered 1.0 carbon steel plate clading.
Heating None
Walkway one
Loading type top outlet and top loading .Загрузка и выгрузка через верхний люк.
Fittings 1 * DN500 lined with PE bolted manhole,1* relief valve with adaptor and bursting disc ,1* DN25 PTFE lined ball valve for air inlet ,1*DN50 PTFE lined ball valve for liquid discharge, 1*DN50 spare provision with blind flange. 1 * DN500,
Others
Painting Acrylic acid and alkali resistant paint, total paint color 120um, color can be specified
Design code ASME VIII Div.1 where applicable and IMDG UN T8 CSC ISO RID/ADR TIR /Customs UIC
Classification Society BV


T14 HCL ISO Tank Container Manufacturer

Hydrofluoric acid and hydrochloric acid tank container belongs to the equipment that exerts significant influence on public security and therefore cannot be modified, added with accessories or filled excessively by user arbitrarily; media should be filled in and unloaded as per the operation regulations on the hydrofluoric acid filling and unloading prepared by the filling and unloading company as well as the regulations on equipment operation safety. Illegal operation is strongly prohibited; the quality of hydrofluoric acid filled must conform to the requirements of relevant standards.

The transport medium of the equipment is hydrofluoric acid and hydrochloric acid, so mixing with other media is strictly prohibited in the transport process.
Special tips: In order to ensure the quality of transport media, if hydrochloric acid is to be transported after unloading of hydrofluoric acid or hydrofluoric acid is to be transported after unloading of hydrochloric acid, the former medium must be cleaned and the tank and pipeline thoroughly cleaned and dried, and the latter medium can be transported after qualified.

The transportation of hydrofluoric acid container tank via highway, waterway or railway must conform to the relevant laws and regulation, and operation specifications such as "Management on the Transportation of Hazardous Articles", "Rules on the Transportation of Hazardous Goods", "Regulations on the Transportation and Loading of Hazardous Goods" and "Laws regarding transportation safety via highway, waterway and railway"; illegal operation is strongly prohibited.

Acid Iso Tank Container

Custermizing Portable iso Tank Container tank container

ISO TANK CONTAINER MAIN TECHNICAL PARAMETERS
20FT TANK CONTAINER Hydrochloric Acid Un1789 33% HCl
Hydrofluoric Acid Un1790 48% HF
OVERALL DIMENSION(MM) 6058×2438×2438/2591
WORKING TEMPERATURE(ºC) -20C0~+55C0
Insulating performance Design according to user's requirement
Water testing pressure(MPa) 0.6
Insulating materials and thickness(mm) optional
Capacity(m3) 17500L
Host materials Middle Steel
SA516 /16MnDR + LLDPE7042 (PE)
Thickness of shell materials(mm) 6
Thickness of Seal Head materials(mm) 6
Corner post materials 16Mn
Standard fittings Manhole cover, valve Two
Type ISO tank containers T14
Capacity Tare weight Max gross weight
21KL 4750kg 36000
Dimensions Metric Imperial
Length 6,058mm 19'10"
Width 2,438mm 8'0"
Height 2,438mm or 2,591mm 8'0" or 8'6"
Pressures Bar MPa
Working pressure 4.0 0.4
Test pressure 6.0 0.6
Shelf material Middle steel
Design Code IMDG ,GB150 ,UN division where applicable
Temperatures °C
Maximum cargo temperature -20C0~+55C0
Approvals Approvals BV
Standard fittings
Manlid 500mm (20") diameter and
Gaskets and seals SWR (sweet white rubber) and PTFE (Teflon)
Certifications

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

we offer All Country CO ,TS,CCS,BV, ASME Report Certificates

General Certificate of origin

Asia Pacific Trade Agreement certificate

GSP certificate of origin

Certificate of origin of China ASEAN Free Trade Area

Certificate of origin of products exported to the EU under the special arrangement for non preferential import

National Tobacco authenticity certificate

Certificate of origin of China Pakistan Free Trade Zone

Certificate of origin of China Chile Free Trade Zone

Certificate of origin of China Singapore Free Trade Zone

Certificate of origin of China New Zealand Free Trade Area

Certificate of origin of China Peru Free Trade Zone

Cross strait certificate of origin

Certificate of origin of China Costa Rica Free Trade Zone

Certificate of origin of China Iceland Free Trade Zone

Certificate of origin of China Switzerland Free Trade Zone

China Iceland free trade statement

China Switzerland free trade statement

Machining and assembly certificate

Transit certificate

Certificate of origin of China Australia Free Trade Area

Certificate of origin of China Georgia Free Trade Zone

Certificate of origin of China Korea Free Trade Zone

Certificate of origin for price commitment of ceramic tiles exported to Mexico

Certificate of origin for price commitment of ceramic tiles exported to Pakistan

Certificate of origin of China Mauritius free trade agreement
GSP FORM A ,CERTIFICATE OF ORIGIN ,CCPIT CEERTIFICATE OF ORIGIN,FTA FORM E,FORM P,FORM F,FORM K,FAU, FORM L...

The bulk liquids that can be transported in an ISO tank include :

Swap body tank ISO tank , ISO Tank Containers- a swap body has a bigger tank which is larger than the frame, usually 23 or 25 feet (7.01 or 7.62 meters) long

Food-grade tank - ISO tank , ISO Tank Containers- a standard tank container which can only be loaded with foodgrade products

ISO tank , ISO Tank Containers Reefer tank - a tank with the ability to cool the product to be transported

ISO tank , ISO Tank ContainersGas tank - a tank that is suitable for the transport of gases

Silo tank ISO tank , ISO Tank Containers- a tank for the transport of grains and powders

T1 ISO tank container for wine and light liquids (ISO tank , ISO Tank Containers)

T4 ISO tank container for non-hazardous edible and non-edible oils (ISO tank , ISO Tank Containers)

T11 ISO tank container for non-hazardous chemicals - ISO tank , ISO Tank Containers

T14 ISO tank container for hazardous chemicals and acids like HCl and zinc chloride - ISO tank , ISO Tank Containers

T50 ISO tank container for LPG and ammonia gas - ISO tank , ISO Tank Containers

SWAP tank container (for cargo above 26,000 to 32,000 metric tons or 25,600 to 31,500 long tons or 28,700 to 35,300 short tons ISO tank , ISO Tank Containers

Rubber-lined ISO tank container for acid-based chemicals best for ISO tank , ISO Tank Containers

PE Lined steel tanks for hydrofluoric acid liquid ,hydrochloric acid ,sodium hypochlorite HCl,NaOH,NaClO liquid etc.

Hazardous chemicals

Acid

Petroleum

Packaging & Shipping

Offer MBL,HBL,BL AWB, Telex Release BL.
Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)

Tank Container Imo1, Imo 5 ISO Tank for Acid Fuel Gas (20, 000 Liter. 24, 000 Liter)
ISO Tank -
Ammonium Nitrate

ISO Tank - Bio-diesel
ISO Tank - Molasses
ISO Tank - Caster Oil
ISO Tank - Hexane
ISO Tank - Ethanol
ISO Tank - Ethylene
ISO Tank - Methanol

ISO Tank - IMO 1
ISO Tank - IMO 2
ISO Tank - IMO5
ISO Tank - Capacities ranging from 10,000 litres to 25,000 litres
ISO Tank - Swap Bodies with capacities ranging from 26,000 litres to 32,000 litres
ISO Tank - Bitumen tank containers 21,000 litres
ISO Tank - Off-shore tanks with capacities of 1,000 litres to 10,000 litres
IMO 1
ISO Tank - Shell made from 316 Stainless Steel
ISO Tank - Capacity of 12,000 - 26,500 litres nominal
ISO Tank - MAWP of 4 bar
ISO Tank - For transport of:
ISO Tank - Hazardous liquids
ISO Tank - Available in 7.65, 10, 20, or 30 foot sizes
ISO Tank - Also Swap-bodies 7.65m and 7.82 (30,000-35,000 litres)
ISO Tank - Heating by steam or electric heating (optional)
ISO Tank -
Cooling by Glycol (optional)
Please contact us if you require further information and/or a quotation. (Contact Details above)
IMO 2
ISO Tank - Shell made from 316 Stainless Steel
ISO Tank - Capacity of 12,000 - 26,500 litres nominal
ISO Tank - MAWP of 1.75 bar
ISO Tank - For transport of:
ISO Tank - Low Hazardous liquids
ISO Tank - Available in 7.65, 10, 20, or 30 foot sizes
ISO Tank - Also Swap-bodies 7.65m and 7.82 (30,000-35,000 litres)
ISO Tank - Heating by steam or electric heating
ISO Tank - Cooling by Glycol
Please contact us if you require further information and/or a quotation. (Contact Details above)
IMO 0
ISO Tank - Shell made from 316 Stainless Steel
ISO Tank - Capacity of 12000 - 26500 litres nominal
ISO Tank - MAWP of 4 bar
ISO Tank - For transport of
ISO Tank - Wine
ISO Tank - Fruit Juices
ISO Tank - Vegetable Oils
ISO Tank - Mineral Oils
ISO Tank - Non-hazardous Oils
ISO Tank - Available in 20 foot / 6 metres
ISO Tank - Also Swap-bodies 7.65m and 7.82 (30,000-35,000 litres)
ISO Tank - Heating by steam or electric heating (optional)
ISO Tank -
Cooling by Glycol (optional)
Please contact us if you require further information and/or a quotation. (Contact Details above)
IMO 5
ISO Tank - Shell made from 316 Stainless Steel
ISO Tank - Capacity of 15,000 - 25,500 litres nominal
ISO Tank - MAWP of 1.75 bar
ISO Tank - For transport of gases, including:
ISO Tank - Propane
ISO Tank - Butane
ISO Tank - Refrigerants
ISO Tank - Available in 20, 30 or 40 foot sizes
ISO Tank - Cooling by sun-shieldPlease contact us if you require further information and/or a quotation. (Contact Details above)IMO 7
ISO Tank - Shell made from 316 Stainless Steel or Carbon Steel
ISO Tank - Capacity of 20,000 - 24,000 litres nominal
ISO Tank - MAWP of 8 bar
ISO Tank - For transport of cryogenic gases, including:
ISO Tank - LNG
ISO Tank - Available in 10, 20, 30 or 40 foot sizes
ISO Tank - Cooling by glycolPlease contact us if you require further information and/or a quotation. (Contact Details above)
Bitumen Tank Containers
ISO Tank - Shell made from Carbon Steel
ISO Tank - Capacity of 20,000-25,000 litres nominal
ISO Tank - MAWP of 1.75 bar
ISO Tank - Low Hazardous liquids
ISO Tank - Available in 20 or 30 foot sizes
ISO Tank - Also Swap-bodies 7.15m (30,000 litres) and 7.82 (35,000 litres)
ISO Tank - Heating by direct flame, hot oil or electric heatingPlease contact us if you require further information and/or a quotation. (Contact Details above)
Cement Containers
ISO Tank - Capacity of 17.5 - 25 cubic metres
ISO Tank - Pressure dischargeOffshore
ISO Tank - Shell made from 316 Stainless Steel
ISO Tank - Capacity of 2,000 - 10,000 litres
ISO Tank - MAWP of 5 bar
ISO Tank - For transport of gases, including:
ISO Tank - Hazardous chemicals
ISO Tank - Acid
ISO Tank - Petroleum
ISO Tank - Available in 8 x 8 x 10 sizes
ISO Tank - Heated by steam or electric (optional)
Steel Lined LDPE aslo for Steel Lined LDPE aslo for HCL(max 35%), NaOH (max 50%), NaCLO (max 10%), PAC (max 17%),H2SO4(60%,98%) ,HF ( 48%),H3PO4 (10%-85%),NH3. H2O,H2O2 (30%)

Previous:
Next:

Related Products

Contact

 Address: R 23, F4,New Factory (4), B1, Phase II, Dashu Industrial Village , Liufang Street ,Wuhan East Lake Hi-tech Development Zone, Wuhan City, Hubei Province,P.R.China
Keystone Vessel Manufacturing Co., Ltd  Add :No.333,2nd Youyi Road,Lishan Town, Sui County,Hubei Province.
Phones: +86-152-7135-7675    https://ks-vessel.com
Email: isotanks@foxmail.com jin@ks-vessel.com
Copyright © 2023-2033 Keystone Vessel (Wuhan) Co., Ltd , Keystone Vessel Manufacturing Co., Ltd  All Rights Reserved  Hubei Dong Runze Special Vehicle Equipment Co.,Ltd
Leave a Message
Contact Us
