High Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas Cylinders

5 0 Reviews
Share to:
sharethis sharing button
Availability:
Quantity:

High Purity Electronic Gas Cylinder for CHF3 ,NF3 ,SF6 ,SiH4, N2O 16.6MPa 440L, 470L Skid Mounted Gas Cylinders
Y-ton Gas Cylinder for SF6 N2O and other Industrial Gases (High Purity Gas Cylinder Y-ton 440L /470L N2, HE, SF6, NF3, N2O )

High Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas Cylinders
470L Y-Ton Gas Cylinder CO, CO2, CH4, N2, O2, HE, SF6, NF3, N2O.


- High Pressure Cylinder
- Gas Production and Filling Y-ton Gas Cylinder for SF6 N2O and other Industrial Gases High purity cylinder

The Y-ton cylinder is used for the storage and supply of high-purity electronic gases. It guarantees safe, reliable storage and transportation of corrosive gases.

Standard: DOT-3AAX/3T, Enric enterprise standard, ISO 11120
Working Pressure: 16.6MPa or as per customer requirements
Water Volume: 440L, 470L or as per customer requirements
The Y-ton cylinder is applicable for SiH4, NF3, N2O, mixed gas of F2 & N2, and other electronic gases.

Y-cylinder(Ton-container) Product features
China standard line of cylinders in production. Volume of Y-Ton cylinder is 440L-470L
Y-Ton cylinder could be designed and manufactured with different code including DOT, ISO. We could always fulfil proposal with different working pressure based on customer's condition and requirement.
Our Y-Ton cylinders are already widely used for famous international gas company in world, such as Air product, Linde, Air Liquide ,Taiyo Nippon Sanso etc. with cost-effective & high performance feature.
Y-ton Gas Cylinder for SF6 N2O and other Industrial Gases
High Purity Gas Cylinder Parameter:
High Purity Gas Cylinder Items Specs
vessel categories 3
filling media SF6
per cylinder weight/kg 535
design wall thickness/mm 15
frame weight/kg 145
cylinder inner wall roughness 12.5μm
leak rate/Pa.m3/s 1.0×10-5
painting color silver grey
design pressure/MPa 16.6
working pressure/MPa 15
design tempressure /ºC -40~60
hydraulic pressure/MPa 27.7
per cylinder nominal capacity/L 450
water content/ppm ≤10.0
end plug material 304
valve material 316L

High purity cylinder mass detection:
High purity internal cylinders gas purity within 2 years without change (high purity special temperament warranty period of 2 years), no change in purity is gas CO, CO2, CH4, N2, O2, moisture, content did not change.
Safety and efficiency are most important factors, they are widely used around world and enjoy high reputation Enric has business to do inspection for Y-ton cylinder with DOT regulation . to do this job, Enric factory is already approved by DOT with HSB as third party to audit and issue inspection report or certificate . The feature of the product 1. The advanced manufacture technology and equipment, feasible quality insurance system; 2. Cylinder standard can be DOT or ISO, and also can be mixed DOT&ISO to make product world used . 3. Y-Ton cylinder can get DOT,TPED, Selo, TPED and KGS certificate separately or together . which will make Y-ton cylinder transporting gas around world, such as taking gas from Taiwan to Vietnam. 4. Complete manifold adopts EP class pipe, CGA valves, and orbital welding process; 5. Helium leakage test rate reaches to 1*10-7 pa.m3/s; 6. Roughness: 0.2~0.8μm; Moisture level: 0.5~1ppm; Particle content(NVR): 50~100mg/m2.. Strict quality control and management system to guarantee the product with high quality which has got Linde audit and approval

High Purity Gas Cylinder Y-ton

Model No Water Capacity Diameter Length Weight Gas Capacity Filling pressure Test pressure
(liter) (mm) (mm) (kg) (m3) (Mpa) (Mpa)
233 440 609.6 2,115 556 73 166 276
225B 470 609.6 2,235 630 78 166 276

high purity gas cylinder Y-ton for Nitrogen, helium...
High Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersHigh Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersY-Ton Cylinder | Gas Cylinder High Purity Electronic Gas Cylinder for CHF3, NF3, Sf6, Sih4, Cl2, N2o 16.6MPa 440L, 470L Skid Mounted Gas CylindersY - Ton bottle for storage and supply of high purity medium is very safe and reliable
guarantee, it save the residence time for the user and operating costs.
Cylinder standard: GB33145
Working pressure: 16.6mpa(2400psi)
Test pressure:27.7mpa
Material is 4130X.
Working temperature:-40ºC~60ºC
Filling medium is high purity N2, HE, SF6, NF3, N2O.
Bottle internal treatment is:1S/3S/25S
Valve brand : Rotarex
Valve quantity: 1pcs
Valve inlet thread: 3/4NGT outlet thread :CGA712
Valve model :D30410036 C=3/4NGT, A=DISS712,Vespel seat for N2O,3360psi and 165F.

Y-Ton Cylinder | Gas Cylinder

Model Capacity
(L)
Cylinder Dia
(mm)
thickness
(mm)
length
(mm)
Cylinder weight
(kg)
Total weight
(kg)
610-440-16.6I 440 610 15 2120 ~527 ~647
610-470-16.6I 470 610 15 2235 ~555 ~675


Application:
Dongrun CNG tube trailer/trailers are widely used in sectors of gas storage, NGV station, CNG tank trailer, and CNG power generating plant and etc. Meanwhile our cylinder skid/trailers are also applied for the storage and transportation of hydrogen, oxygen, nitrogen, argon, helium, purified gas and other kinds of gases.
Features of Dong RunZe high-pressure gas cylinder:
1. Heat-spinning technology;
2. Walking beam continuous heat treatment;
3. Large-size structure and fewer valves, tubes and joints;
4. Concise design, less maintenance on site;
5. Lower weight of design;
6. Additional gas-filling devices.

The unpowered gas station technology, in the parent station, consumes 690 degrees of electricity for every 10000 cubic meters of CNG to 25MPa pressurized (more than 80 degrees of electricity is consumed by about 2000 cubic meters of 20MPa to 25MPa pressurized). It is transported to the sub station by 25MPa cylinder Trailer. With the patented technology of "multi cylinder alternating circulation", the secondary pressurization equipment is no longer needed, and the inflated cylinder can be filled to 20MPa. No noise and pollution emissions, real energy conservation and environmental protection. Compared with the same conditions, for every 10000 cubic meters of CNG sold, the power consumption of secondary pressurization is 1160-690 = 470 degrees. The energy consumption of different compressor models is slightly different
25MPa Intelligent CNG Dispenser Filling Station
Winding Cylinder Trailer, No Need For Secondary Pressure, Save Compression Equipment, Save Power
Skid Mounted Mobile Lng/L- Cng Filling Station With Cng Dispenser Lng Dispenser CNG Tank Trailer

Compact structure,integrated design and less occupied area,convenient for transportation and installation. Adopt high quality sound-proof material, lower working nosies, can meet different environmental requirement from different area. Adopt full air cooling,natural gas and fydraulic oil use the same cooler. Hydraulic cylinder adopts the vertical type; one cylinder can realize two-stage gas compression;oil and gas can be totally separated, and with no oil consumption.

6 Tube CNG Tank Trailer with 25.02m3 Total Cylinder

CNG TUBE CASCADE SKID CONTAINER

Model

9401GGY

Name

Compressed Nature Gas Long Tube Transportation Semi Trailer

Brand

DONGRUNZE

Announcement

267 Batch

Volume

25.02m³

Dimension

13000mm*2480mm*3140mm

Rated Load

4340kg

Tare Weight

35660kg

Total Weight

40000kg

Vehicle Identification Number

LA99FRG3×××SKW×××

Usage

The cargo's carrying part is 6 tubes tank-style designed, is suitable for the transportation of compressed natural gas.

Remarks

Total volume of tank: 25.02m³, Transport medium: CNG, Medium density: 170kg/m³, Tank is composed of 6 tubes.

UPPER CONSTRUCTION

Standard:ISO11120-19999 Q/1500ZTL 002-2012

Tube Skid Container

Items

Parameter

Cylinder

Items

Parameter

Type

GSJ08-2210-CNG-25

Working Pressure

25MPa

Net Weight(without Chassis)

26762Kg

CNG Loading Weight

4010Kg

Working

Temperature

-50~65°C

Rated Weight

30772Kg

Main material

4130X

Risk Class

2.1

Cylinder Quantity

6

UN code

1049

Loading Medium

CNG

Total Cylinder Volume

25.02m3

Leakage test pressure

25MPa

Hydrostatic test pressure

37.5MPa

Inflating Volume

6300Nm3(20ºC)

dimension(Diameter x Thickness x Length)

Φ711x17.4x12190

Heat Treatment

Quenching+

Tempering

Design

Temperature

65ºC

outside dimension

12192x2438x1400

(mm)

Working

Temperature

-40~60°C

Leakage test pressure

25MPa

Medium Property

Explosive

Bursting Disc

Bursting Pressure

37.5MPa

material

4130X

Bursting Disc Device Discharging Diameter

≥ φ20

material

4130X
