Availability: | |
---|---|
Quantity: | |
Images of Un1005 Tank
UN 1005: Ammonia, anhydrous isotank Anhydrous Ammonia Tank
UN 1005 AMMONIA, ANHYDROUS
UN1075 iso tank
UN1075 Propane (ASME Storage Tanks / ISO Transportable Tanks)
Wholesale 20FT LPG ISO Tank Container 24000L 20FT LPG (Propane) ISO Tank Container ASME Standard 24m3 Design 15 years
Custermizing Container Trailer Mounted
20ft lpg iso tank container, 20ft lpg iso tank container
Images of 20ft LPG Tank Containers
ASME Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | SA-612M | SA-612M |
Design Capacity | 24.7m3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 350000KG | 36000KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 0mm | 0mm |
ASME Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | SA-612M | SA-612M |
Design Capacity | 24.7m3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 350000KG | 36000KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 0mm | 0mm |
Chinese Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | 16MnDR | WH590E |
Design Capacity | 25M3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 19450KG | 34014KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8 MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 1.0mm | 15 years |
Design specification:TSG R005, GB150,…… | |
Design pressure: 1.8mpa | Loading medium: LPG (propane) |
Geometric volume: 24 m3 | Design temperature range: - 40 ~ 50 ºC |
Corrosion allowance: 1 mm | Loading and unloading type: lower loading and unloading |
Weight of equipment: 7350 kg | Maximum allowable total mass: 34000 kg |
Form of heat preservation: shading | Dimensions (length * width * height) : 6058 * 2438 * 2591 |
Part name | Material grade | Dimensions and specifications | Qty | kg |
Cylinder | Q345R hot rolled | φ2370×14(12.66) L=4570 | 1 | 3802 |
Head | Q345R hot rolled | EHA2370×15(12.70) | 2 | 747×2=1494 |
Forgings | 16Mn | normalizing | 300 | |
Ram Board | Assembly | 256 | ||
Connected To The Cylinder | Q345-D | t=6 | 260 | |
Support Ring | 140 | |||
The Framework | Q345-D | 150×150×5 | 750 | |
Visor | Alloy | t=2 | 78 | |
Other | Q235-A | 200 | ||
Valve | 70 |
Iterm | Specifications, Models | Quantity | M |
The relief valve | DN80 | 1 | VALE |
Rupture discs | N | 1 | |
Gas valve | DN50 | 1 | VALE |
The liquid valve | DN50 | 1 | VALE |
Tossing in valve | Q21F-64P | 2 | |
Level gauge | |||
Pressure gauge | YN-100BF-Z(0~4.0MPa) | 1 | |
Pressure gauge valve | J21W-64P | 1 | |
The thermometer | WSS-401J-1.5 | 1 |
Type | : | ISO 1496/3 (1CC ). |
Dimensions | : | 6,058mm long x 2,438mm wide x 2,591mm high. |
Material | : | SPA-H or equivalent. |
Corner casting | : | To ISO 116 |
Miscellaneous frame | : |
|
Chinese Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | 16MnDR | WH590E |
Design Capacity | 25M3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 19450KG | 34014KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8 MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 1.0mm | 15 years |
The Main Technical Parameters of Tanks (ASME Standard) | ||||||||||||
| Loading Medium | Model | Capacity | Design | Design | Tank Material | Nominal Tank | Insulation | Tare weight | Max. Gross Weight | Dimension | Loading Method |
1 | R134a | T50 | 24 | 1.38 | -40 /+55 | SA-612N | 11 | Sunshade | 6400 | 34000 | 6058 X 2438 X2591 | Down load unload |
2 | R22 | 22 | 2.1 | -40/+50 | 18 | 8800 | ||||||
3 | R143a | 22 | 2.42 | 20 | 9500 | |||||||
4 | R125 | 22 | 2.75 | 21 | 9500 | |||||||
5 | R32 | 20 | 3.44 | 25 | 10900 | |||||||
6 | AHF | T19 | 21 | 1.0 | -40/+55 | SA516M NGr.485 | 12 | No | 6900 | Up load unload | ||
7 | Trichlorosilan | T14 | 21 | 0.5 | -40/+50 | Q345R | 12 | No | 6780 | 34000 | 6058 X 2438 X2591 | |
8 | Liquid Chlorine | T50 | 20 | 1.7 | -40/+50 | 16 | 8300 | |||||
9 | 21.72 | 1.62 | 16 | 8900 | ||||||||
10 | Liquid | T50 | 21.6 | 2.2 | -40/+50 | 06Cr19Ni10 | 22 | Packing Insulation | 11970 | |||
11 | SO2 | T20 | 21 | 1.03 | 40 /+60 | 16MnDR | 12 | No | 6900 | |||
12 | Cryogenic Liquid | T75 | 19.8,20 | 0.75-2.35 | -196/+50 | Inner Tank: 06Cr19Ni10 | Vacuum With Mutli-wrapped | 8600/12880 | Down load unload | |||
The Main Technical Parameters of Tanks (China Standard) | ||||||||||||
| Loading Medium | Model | Capacity | Design | Design | Tank Material | Nominal Tank | Insulation | Tare weight | Max. Gross Weight | Dimension | Loading Method |
1 | R134a | T50 | 24 | 1.38 | -40 /55 | Q345 (16MnR) | 12 | Sunshade | 6500 | 34000 | 6058 X 2438 X2591 | Down load unload |
2 | R22 | 20 | 2.1 | -40/+50 | 16 | 7850 | ||||||
3 | 24 | 18 | 9100 | |||||||||
4 | R125 | 22 | 2.75 | 22 | 9900 | |||||||
5 | R32 | 22 | 3.44 | 28 | 12000 | |||||||
6 | 23.7 | -40 /55 | 12700 |
T9, T10,T11,T14,T50 portable tank Standard ISO tank 10.9K-26K cement tank,
PTFE/PE Lined tanks for hydrofluoric acid liquid ,hydrochloric acid ,sodium hypochlorite HCl,NaOH,NaClO liquid etc.
Insulation Tank for bitumen Liquid Asphalt,crude oil etc.Portable Tank Container
Tank Containers can be used to carry the following products:
Portable Tank Container
Products
ISO Tank - Ammonium Nitrate
ISO Tank - Bio-diesel
ISO Tank - Molasses
ISO Tank - Caster Oil
ISO Tank - Hexane
ISO Tank - Ethanol
ISO Tank - Ethylene
ISO Tank - Methanol
ISO Tank
ISO 40' LNG Tank Container | Bitumen tank container | ISO 20' Tank Container |
IMO 1 | IMO 2 | IMO 5 |
LPG Storage Tanks Above-ground LPG Storage Tank
I. Chinese GB Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload (90% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
10m³ | 1600mm | 5300mm | 2370mm | 3400kg | 4035kg | 8.53mm | 8.51mm |
12m³ | 1600mm | 6300mm | 2370mm | 3800kg | 4850kg | ||
20m³ | 2200mm | 5680mm | 2970mm | 5150kg | 8070kg | 11.35mm | 11.33mm |
25m³ | 2200mm | 7000mm | 2970mm | 6000kg | 10090kg | ||
32m³ | 2200mm | 8850mm | 2970mm | 7200kg | 12920kg | ||
40m³ | 2470mm | 8843mm | 3240mm | 8780kg | 16410kg | 12.62mm | 12.59mm |
50m³ | 2470mm | 10903mm | 3240mm | 10420kg | 20180kg | ||
63m³ | 2470mm | 13623mm | 3240mm | 12600kg | 25420kg | ||
80m³ | 3100mm | 11170mm | 3800mm | 16700kg | 32280kg | 15.58mm | 15.87mm |
100m³ | 3100mm | 13850mm | 3800mm | 20000kg | 40350kg | ||
150m³ | 3400mm | 17140mm | 4104mm | 29800kg | 60500kg | 17.35mm | 17.31mm |
200m³ | 3800mm | 18324mm | 4560mm | 40100kg | 80700kg | 19.27mm | 19.22mm |
Main Material | Q345R | Design Pressure | 1.61MPa |
Hydraulic Test Pressure | 2.22MPa | Working Pressure | ≤1.61MPa |
Corrosion Allowance | 1.0mm | Design Temperature | -20/50ºC |
Life Expectancy | 20 years | Working Temperature | -20/50ºC |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
II. ASME Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload (85% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
10m³ | 1600mm | 5308mm | 2440mm | 3850kg | 4630kg | 11.09mm | 11.02mm |
12m³ | 1600mm | 6308mm | 2440mm | 4340kg | 5560kg | ||
20m³ | 2200mm | 5690mm | 3050mm | 6920kg | 9260kg | 14.86mm | 14.78mm |
25m³ | 2200mm | 7010mm | 3050mm | 8100kg | 11580kg | ||
32m³ | 2200mm | 8860mm | 3050mm | 9750kg | 14820kg | ||
40m³ | 2470mm | 8851mm | 3320mm | 11930kg | 18530kg | 16.56mm | 16.47mm |
50m³ | 2470mm | 10911mm | 3320mm | 15420kg | 25470kg | ||
60m³ | 2470mm | 13001mm | 3320mm | 16600kg | 27790kg | ||
80m³ | 3100mm | 11178mm | 3960mm | 22820kg | 37060kg | 20.53mm | 20.41mm |
100m³ | 3100mm | 13858mm | 3960mm | 27430kg | 46320kg |
Main Material | SA-516 Gr.70 | Design Pressure | 1.724MPa |
Hydraulic Test Pressure | 2.25MPa | Working Pressure | ≤1.724MPa |
Corrosion Allowance | 1.0mm | Design Temperature | 50ºC |
Specific Gravity | 0.545@15ºC | Working Temperature | -20/50ºC |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
Chinese GB Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload(90% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
7m³ | 1200mm | 6560mm | 2430mm | 3100kg | 2820kg | 7.5mm | 6.64mm |
10m³ | 1600mm | 5300mm | 2870mm | 3800kg | 4035kg | 8.53mm | 8.51mm |
20m³ | 2000mm | 6800mm | 3290mm | 5900kg | 8070kg | 10.41mm | 10.39mm |
25m³ | 2200mm | 7000mm | 3484mm | 6300kg | 10090kg | 11.36mm | 11.33mm |
50m³ | 2470mm | 10903mm | 3756mm | 11220 | 20180kg | 12.62mm | 12.59mm |
Main Material | Q345R | Design Pressure | 1.61MPa |
Hydraulic Test Pressure | 2.22MPa | Working Pressure | ≤1.61MPa |
Corrosion Allowance | 1.0mm | Design Temperature | -20/50ºC |
Life Expectancy | 20 years | Working Temperature | -20/50ºC |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
ASME Standard | |||||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload (90% Filling Ratio) | Material | Design Pressure | Thickness | |
Shell | Heads | ||||||||
22m³ | 2000mm | 7420mm | 2774mm | 6200kg | 8876kg | Q345R | 1.61MPa | 11.56mm | 10.47mm |
98.5m³ | 3500mm | 11588mm | 3548mm | 25100kg | 47073kg | SA-516 GR.70 | 1.724MPa | 23.05mm | 13.21mm |
124m³ | 3450mm | 14410mm | 5140mm | 26500kg | 60890kg | 1.38MPa | 18.98mm | 10.28mm | |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
Images of Un1005 Tank
UN 1005: Ammonia, anhydrous isotank Anhydrous Ammonia Tank
UN 1005 AMMONIA, ANHYDROUS
UN1075 iso tank
UN1075 Propane (ASME Storage Tanks / ISO Transportable Tanks)
Wholesale 20FT LPG ISO Tank Container 24000L 20FT LPG (Propane) ISO Tank Container ASME Standard 24m3 Design 15 years
Custermizing Container Trailer Mounted
20ft lpg iso tank container, 20ft lpg iso tank container
Images of 20ft LPG Tank Containers
ASME Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | SA-612M | SA-612M |
Design Capacity | 24.7m3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 350000KG | 36000KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 0mm | 0mm |
ASME Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | SA-612M | SA-612M |
Design Capacity | 24.7m3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 350000KG | 36000KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 0mm | 0mm |
Chinese Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | 16MnDR | WH590E |
Design Capacity | 25M3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 19450KG | 34014KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8 MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 1.0mm | 15 years |
Design specification:TSG R005, GB150,…… | |
Design pressure: 1.8mpa | Loading medium: LPG (propane) |
Geometric volume: 24 m3 | Design temperature range: - 40 ~ 50 ºC |
Corrosion allowance: 1 mm | Loading and unloading type: lower loading and unloading |
Weight of equipment: 7350 kg | Maximum allowable total mass: 34000 kg |
Form of heat preservation: shading | Dimensions (length * width * height) : 6058 * 2438 * 2591 |
Part name | Material grade | Dimensions and specifications | Qty | kg |
Cylinder | Q345R hot rolled | φ2370×14(12.66) L=4570 | 1 | 3802 |
Head | Q345R hot rolled | EHA2370×15(12.70) | 2 | 747×2=1494 |
Forgings | 16Mn | normalizing | 300 | |
Ram Board | Assembly | 256 | ||
Connected To The Cylinder | Q345-D | t=6 | 260 | |
Support Ring | 140 | |||
The Framework | Q345-D | 150×150×5 | 750 | |
Visor | Alloy | t=2 | 78 | |
Other | Q235-A | 200 | ||
Valve | 70 |
Iterm | Specifications, Models | Quantity | M |
The relief valve | DN80 | 1 | VALE |
Rupture discs | N | 1 | |
Gas valve | DN50 | 1 | VALE |
The liquid valve | DN50 | 1 | VALE |
Tossing in valve | Q21F-64P | 2 | |
Level gauge | |||
Pressure gauge | YN-100BF-Z(0~4.0MPa) | 1 | |
Pressure gauge valve | J21W-64P | 1 | |
The thermometer | WSS-401J-1.5 | 1 |
Type | : | ISO 1496/3 (1CC ). |
Dimensions | : | 6,058mm long x 2,438mm wide x 2,591mm high. |
Material | : | SPA-H or equivalent. |
Corner casting | : | To ISO 116 |
Miscellaneous frame | : |
|
Chinese Standard LPG ISO Tank Container | ||
| 20ft | 40ft |
Material | 16MnDR | WH590E |
Design Capacity | 25M3 | 51.7m3 |
Medium | LPG | LPG |
Tare Mass | 6500KG | 12300KG |
Max. Gross Mass | 19450KG | 34014KG |
Tank Outline Dimension( ID * H * L) | 6058*2438*2591mm | 12192*2438*2591mm |
Design pressure | 1.8 MPa | 1.8 MPa |
Allowable Working pressure | 1.8 MPa | 1.8 MPa |
Working Temperature | -40~50 ºC | -40~50 ºC |
Design Temperature | 55 ºC | 55 ºC |
Design Service Life | 15 years | 15 years |
Corrosion Allowance | 1.0mm | 15 years |
The Main Technical Parameters of Tanks (ASME Standard) | ||||||||||||
| Loading Medium | Model | Capacity | Design | Design | Tank Material | Nominal Tank | Insulation | Tare weight | Max. Gross Weight | Dimension | Loading Method |
1 | R134a | T50 | 24 | 1.38 | -40 /+55 | SA-612N | 11 | Sunshade | 6400 | 34000 | 6058 X 2438 X2591 | Down load unload |
2 | R22 | 22 | 2.1 | -40/+50 | 18 | 8800 | ||||||
3 | R143a | 22 | 2.42 | 20 | 9500 | |||||||
4 | R125 | 22 | 2.75 | 21 | 9500 | |||||||
5 | R32 | 20 | 3.44 | 25 | 10900 | |||||||
6 | AHF | T19 | 21 | 1.0 | -40/+55 | SA516M NGr.485 | 12 | No | 6900 | Up load unload | ||
7 | Trichlorosilan | T14 | 21 | 0.5 | -40/+50 | Q345R | 12 | No | 6780 | 34000 | 6058 X 2438 X2591 | |
8 | Liquid Chlorine | T50 | 20 | 1.7 | -40/+50 | 16 | 8300 | |||||
9 | 21.72 | 1.62 | 16 | 8900 | ||||||||
10 | Liquid | T50 | 21.6 | 2.2 | -40/+50 | 06Cr19Ni10 | 22 | Packing Insulation | 11970 | |||
11 | SO2 | T20 | 21 | 1.03 | 40 /+60 | 16MnDR | 12 | No | 6900 | |||
12 | Cryogenic Liquid | T75 | 19.8,20 | 0.75-2.35 | -196/+50 | Inner Tank: 06Cr19Ni10 | Vacuum With Mutli-wrapped | 8600/12880 | Down load unload | |||
The Main Technical Parameters of Tanks (China Standard) | ||||||||||||
| Loading Medium | Model | Capacity | Design | Design | Tank Material | Nominal Tank | Insulation | Tare weight | Max. Gross Weight | Dimension | Loading Method |
1 | R134a | T50 | 24 | 1.38 | -40 /55 | Q345 (16MnR) | 12 | Sunshade | 6500 | 34000 | 6058 X 2438 X2591 | Down load unload |
2 | R22 | 20 | 2.1 | -40/+50 | 16 | 7850 | ||||||
3 | 24 | 18 | 9100 | |||||||||
4 | R125 | 22 | 2.75 | 22 | 9900 | |||||||
5 | R32 | 22 | 3.44 | 28 | 12000 | |||||||
6 | 23.7 | -40 /55 | 12700 |
T9, T10,T11,T14,T50 portable tank Standard ISO tank 10.9K-26K cement tank,
PTFE/PE Lined tanks for hydrofluoric acid liquid ,hydrochloric acid ,sodium hypochlorite HCl,NaOH,NaClO liquid etc.
Insulation Tank for bitumen Liquid Asphalt,crude oil etc.Portable Tank Container
Tank Containers can be used to carry the following products:
Portable Tank Container
Products
ISO Tank - Ammonium Nitrate
ISO Tank - Bio-diesel
ISO Tank - Molasses
ISO Tank - Caster Oil
ISO Tank - Hexane
ISO Tank - Ethanol
ISO Tank - Ethylene
ISO Tank - Methanol
ISO Tank
ISO 40' LNG Tank Container | Bitumen tank container | ISO 20' Tank Container |
IMO 1 | IMO 2 | IMO 5 |
LPG Storage Tanks Above-ground LPG Storage Tank
I. Chinese GB Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload (90% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
10m³ | 1600mm | 5300mm | 2370mm | 3400kg | 4035kg | 8.53mm | 8.51mm |
12m³ | 1600mm | 6300mm | 2370mm | 3800kg | 4850kg | ||
20m³ | 2200mm | 5680mm | 2970mm | 5150kg | 8070kg | 11.35mm | 11.33mm |
25m³ | 2200mm | 7000mm | 2970mm | 6000kg | 10090kg | ||
32m³ | 2200mm | 8850mm | 2970mm | 7200kg | 12920kg | ||
40m³ | 2470mm | 8843mm | 3240mm | 8780kg | 16410kg | 12.62mm | 12.59mm |
50m³ | 2470mm | 10903mm | 3240mm | 10420kg | 20180kg | ||
63m³ | 2470mm | 13623mm | 3240mm | 12600kg | 25420kg | ||
80m³ | 3100mm | 11170mm | 3800mm | 16700kg | 32280kg | 15.58mm | 15.87mm |
100m³ | 3100mm | 13850mm | 3800mm | 20000kg | 40350kg | ||
150m³ | 3400mm | 17140mm | 4104mm | 29800kg | 60500kg | 17.35mm | 17.31mm |
200m³ | 3800mm | 18324mm | 4560mm | 40100kg | 80700kg | 19.27mm | 19.22mm |
Main Material | Q345R | Design Pressure | 1.61MPa |
Hydraulic Test Pressure | 2.22MPa | Working Pressure | ≤1.61MPa |
Corrosion Allowance | 1.0mm | Design Temperature | -20/50ºC |
Life Expectancy | 20 years | Working Temperature | -20/50ºC |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
II. ASME Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload (85% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
10m³ | 1600mm | 5308mm | 2440mm | 3850kg | 4630kg | 11.09mm | 11.02mm |
12m³ | 1600mm | 6308mm | 2440mm | 4340kg | 5560kg | ||
20m³ | 2200mm | 5690mm | 3050mm | 6920kg | 9260kg | 14.86mm | 14.78mm |
25m³ | 2200mm | 7010mm | 3050mm | 8100kg | 11580kg | ||
32m³ | 2200mm | 8860mm | 3050mm | 9750kg | 14820kg | ||
40m³ | 2470mm | 8851mm | 3320mm | 11930kg | 18530kg | 16.56mm | 16.47mm |
50m³ | 2470mm | 10911mm | 3320mm | 15420kg | 25470kg | ||
60m³ | 2470mm | 13001mm | 3320mm | 16600kg | 27790kg | ||
80m³ | 3100mm | 11178mm | 3960mm | 22820kg | 37060kg | 20.53mm | 20.41mm |
100m³ | 3100mm | 13858mm | 3960mm | 27430kg | 46320kg |
Main Material | SA-516 Gr.70 | Design Pressure | 1.724MPa |
Hydraulic Test Pressure | 2.25MPa | Working Pressure | ≤1.724MPa |
Corrosion Allowance | 1.0mm | Design Temperature | 50ºC |
Specific Gravity | 0.545@15ºC | Working Temperature | -20/50ºC |
Notes: Above exsited design capacities for you to choose from. If you have any other different requirements, we could also provide you with customized design. |
Chinese GB Standard | |||||||
Water Capacity | Inner Diameter | Overall Length | Height | Weight | Payload(90% Filling Ratio) | Thickness | |
Shell | Heads | ||||||
7m³ | 1200mm | 6560mm | 2430mm | 3100kg | 2820kg | 7.5mm | 6.64mm |
10m³ | 1600mm | 5300mm | 2870mm | 3800kg | 4035kg | 8.53mm | 8.51mm |
20m³ | 2000mm | 6800mm | 3290mm | 5900kg | 8070kg | 10.41mm | 10.39mm |
25m³ | 2200mm | 7000mm | 3484mm | 6300kg | 10090kg | 11.36mm | 11.33mm |
50m³ | 2470mm | 10903mm | 3756mm | 11220 | 20180kg | 12.62mm | 12.59mm |
Main Material | Q345R | Design Pressure | 1.61MPa |
Hydraulic Test Pressure | 2.22MPa | Working Pressure | ≤1.61MPa |
Corrosion Allowance | 1.0mm | Design Temperature | -20/50ºC |
Life Expectancy | 20 years | Working Temperature | -20/50ºC |
