Ext. Length

12144/12192 mm

Ext. Width

2438mm

Ext. Height

2400mm; 2591mm

M.G.W.

90000kg ;92000kg

Tare

11600Kg;

12000kg

Max. Payload

80000Kgs

Cubic Capacity

40m3;44m3

Sulphuric Acid Tank

Tank Design Standard

GB 150 ，GB/ T 16563， GB/ T 1413， GB/ T 1836， GB/ T 1835.

Max. Design Pressure

0.1Mpa

Calculated Pressure

0.1Mpa

Testing Pressure

0.1Mpa

Design Operating Temp.

-20℃～55℃

Lining

PE7042 lined 16mm

Material of Tank Body

Q235

Manhole Dia.

580mm

Tank Body Thickness

6 .0mm

Facilities Tank Capacity: 40,000 Liters;44,000 Liters

Steel sheet 6mm, head 6mm Liner , inner welded reinforcement 4mm steel mesh ,thickness: 16mm~18mm PE;Tank in 40ft rectangular frame, 2 pcs of bottom valves, Connect each outlet pipe,   01pc butterfly valve CS/F46 and 01pc ball valve CS/F46, Both valves are all connected by DN80-DIN PN16 flange, The connection type: butterfly valve - ball valve - connection flange,  protection frame and bracket for the valve , full plastic manhole cover,  the painting of tank is anti-corrosive painting,
